8 Outlet Rack Mount PDU: Variant and Surge Rating Guide

An 8 outlet rack mount PDU can organize power for network, AV, office, and test equipment in a standard rack. Before choosing one, confirm the rack fit, plug spacing, cord route, connected load, and the documentation for the exact color variant.

Verified details for the current 8 outlet PDU

The current 8 outlet rack mount PDU documents the following shared features:

• Eight AC outlets in a metal housing.
• A 1U format designed for a standard 19 inch rack.
• Removable rack ears for compatible mounting arrangements.
• A 6 ft, 16AWG power cord.
• A right-angle wall plug.
• Current black, yellow, and green variants.

The product family is sold as a surge protector, but protection details should be checked at the variant level. Current green-variant media documents 300-joule surge protection and overload protection. That image evidence should not automatically be applied to the black or yellow versions without matching documentation on the selected unit.

Check rack fit before ordering

A 1U label describes vertical rack space, while the 19 inch format describes the standard rack width. Confirm that the mounting ears, rack rails, and screw positions match the intended cabinet. Also check whether the outlet face should point toward the front or rear for easier cable routing.

• Leave access to the power switch and protective device.
• Keep adapters from pressing against the rack door or nearby equipment.
• Support heavy cords so they do not pull on the receptacles.
• Route the 6 ft cord away from sharp metal edges and moving parts.

Plan outlet and adapter spacing

Eight receptacles do not always provide eight usable positions when wide power adapters are connected. List the plug shapes used by routers, switches, computers, chargers, and AV equipment. Place larger adapters where they will not cover the neighboring outlet, and keep frequently disconnected equipment easy to reach.

Calculate the connected load

Outlet count is not the electrical load limit. Add the requirements of equipment that may operate at the same time and compare the total with the rating printed on the selected PDU and its connected branch circuit. Do not use an old article or a similar-looking model as the source for amperage, wattage, certification, or warranty terms.

How to verify surge protection

If a project requires a particular joule rating, certification, or overload feature, verify it on the exact variant before installation. For the current listing, the green version has the clearest documented 300-joule and overload information. Ask for current documentation when those specifications are required for the black or yellow version.

8 outlet rack PDU checklist

1. Choose the black, yellow, or green variant.
2. Confirm 1U space and 19 inch rack compatibility.
3. Measure the 6 ft cord route to the wall connection.
4. Map large adapters across the eight outlets.
5. Total the connected equipment load.
6. Verify surge, overload, certification, and warranty details for the exact variant.
